Function and Features:

The equipment mechanism consists of a bag warehouse mechanism, an automatic bag taking and opening mechanism, an automatic bag supporting and rotating mechanism, an automatic product conveying mechanism, an automatic pushing and bagging mechanism, an automatic bag arranging mechanism, an automatic bag mouth clamping and rotating mechanism, an automatic sealing mechanism, a product conveying and discharging mechanism, a main support mechanism and a control mechanism;
The design of each component of the equipment is based on the efficiency requirement of 20-50pcs/min;
Adopt servo control system, touch screen man-machine interface for clearer display and easier maintenance.

Application Fields:

Widely used for bagging and packaging of products in life, study, electronics, cosmetics, medical and food fields, etc.
Application scenarios: bagging and packaging of towels, bath towels, paper towels, sanitary napkins, bottom-supported box products, bread, foundation boxes and other products.

Technical Parameters:
Input Voltage V: AC220V
Power kW: 8.0kw
Equipment Weight kg: 750kg
Working Air Pressure Mpa: 0.5-0.7Mpa
Equipment Size (LengthWidthHeight) mm: 2940*2910*1425mm
Air Consumption L/min: 600L/min
Applicable Bag Size mm: L100-300mm W70-150mm H40-90mm
Applicable Bag Material: CPP, PT, PE, CPP aluminized film, aluminum film
