Basic Functions:

This machine does not contain a conveyor belt. It uses your company's original assembly line to transport products. The labeling head is directly installed beside the assembly line and can label the side of the product;
Applied to side labeling of products such as finished cartons, refrigerators, large barrels of oil, and other large barrels of heavy products.

Technical Parameters:
Labeling Accuracy: ±1mm
Labeling Speed: 15~120 pcs/min (related to product, label size, and assembly line speed requirements)
Applicable Product Size: No requirement (depending on assembly line conveying parameters)
Applicable Label Size: Length: 6mm~250mm; Width: 6mm~175mm
Overall Machine Dimensions: 900mm*900mm*1150mm (LengthWidthHeight)
Applicable Power Supply: 220V/50Hz
Overall Machine Weight: 70kg
