Machine Tool Features:

The machine tool castings are made of high-quality Meehanite cast iron. Through finite element analysis, the reasonable structural strength and the combination of reinforcing ribs ensure stable structure, not easy to deform, and strong rigidity.
X/Y axes adopt linear guideways, featuring low noise, low friction, etc., enabling rapid displacement and achieving optimal circular accuracy. Z axis uses hard rail combined with Turcite-B with low friction coefficient, which is durable and can obtain optimal cutting rigidity.
The base is wide and solid, the column is a box-type structure, the saddle is widened and lengthened, with heavy load full support design, and the structure is solid, which can ensure the heavy load capacity during processing.
The inside of the spindle box is reinforced with ribs, and the reasonable contact length between the spindle box and the column provides stable support for the spindle.
The three-axis motors are directly driven with precision high-speed ball screws and assembled with pre-positioning to enhance rigidity and improve precision.

Standard Configuration:
· Japanese Mitsubishi CNC system
· Cutting cooling system
· Automatic lubrication system
· Electrical cabinet heat exchanger
· Guideway steel防护罩
· Electronic handwheel
· USB, CF card interface
· Working lighting
· Warning light
· Air gun
Optional Configuration:
· Japanese Fanuc system
· Arm-type tool magazine
· Spindle oil temperature cooling machine
· Automatic chip conveyor
· 4th (5th) axis CNC turntable
· Voltage stabilizer
· Direct-coupled spindle
· Spindle center water outlet
· Spindle ring water outlet
