Machine Tool Features:

Ultra-wide base, made of integrally casted components, featuring three key characteristics: stability, high rigidity, and sturdiness, providing the most stable load-bearing capacity. The worktable is non-overhanging, combined with reinforced design for each axis, maximizing rigidity and stability.
Herringbone column, widened span of the joint surface between the column and the base, effectively enhancing column rigidity and avoiding machining vibration.
Y-axis motor is rear-mounted for easy maintenance, shortening the distance between the operator and the worktable, suitable for loading and unloading workpieces, greatly improving machining convenience.
Three-axis precision ball screws with pre-positioning design, timed and quantitative oil injection to each lubrication point, ensuring uniform lubrication of each sliding surface and effectively reducing sliding friction resistance.
Three-axis guideways are equipped with fully enclosed stainless steel防护罩 (protective covers), providing excellent chip removal and protection performance.

Standard Configuration:
· Mitsubishi CNC system (Japan)
· Cutting cooling system
· Automatic lubrication system
· Electrical cabinet heat exchanger
· Guideway steel protective covers
· Electronic handwheel
· USB and CF card interfaces
· Workpiece lighting
· Warning light
· Air gun
Optional Configuration:
· Fanuc system (Japan)
· Arm-type tool magazine
· Spindle oil temperature cooling machine
· Automatic chip conveyor
· 4th (5th) axis CNC rotary table
· Voltage stabilizer
· Direct-drive spindle
· Spindle center through coolant
· Spindle annular through coolant
