Machine Tool Features:
-This series of machine tools is an automated machining center integrating milling, drilling, tapping, and chamfering, suitable for metal processing of steel, copper, aluminum materials of various lengths and long part processing
-This machine tool adopts an integrated base and full moving column structure design, with reasonable overall layout, compact structure, and small floor area. The rigidity and shock resistance have been effectively improved
-The spindle box of this machine uses a high-speed direct-drive mechanical spindle, suitable for high-speed and high-rigidity cutting, completing various drilling, milling and tapping processes
-The tool magazine is an arm-type disc tool magazine that can realize quick tool change, with a 24-station tool magazine
-The internal protection of the machine tool adopts armor-type shield protection, which effectively protects the lead screw, linear guide, rack, etc.
Standard Configuration:
·Taiwan Syntec system
·Semi-protective sheet metal
·Three-axis linear guide
·Three-axis protective cover
·Cutting coolant system
·Automatic centralized lubrication system
·Electronic handwheel
·USB, CF card interface
·Three-color warning light
·Tools and toolbox
·Leveling bolts and foundation blocks
·BT40-24T arm-type tool magazine
·Spindle oil temperature cooling machine
·Chain chip conveyor
Optional Configuration:
·Japan Fanuc/Mitsubishi system
·Tool body, cutting tools, fixtures
·Fourth (fifth) axis CNC turntable
