Machine Tool Features:

The base casting is processed by a high-precision five-face gantry, completing five-face milling, drilling, and tapping in one clamping, reducing clamping errors and improving machining accuracy
KMH-630 (inclusive) and above bases adopt the popular inverted "T" layout, with high rigidity of the overall structure and no overturning torque generated during the full stroke
The indexing table is 1°x360, positioned by a ratchet disc, with high positioning accuracy
The lead screw uses a set of 60° angular contact ball bearings, with double support and pre-stretching to ensure transmission accuracy
Heavy-duty high-precision roller guides, capable of withstanding heavy-load cutting and having good shock absorption
Adopting Taiwan high-precision spindle with standard speed and spindle air curtain protection device to ensure stable spindle accuracy and long service life
The spindle is driven by a high-power dual-winding servo motor with large output torque
Intermittent centralized lubrication system, periodically and quantitatively supplying oil to each lubrication point, forming and maintaining an appropriate oil film on the friction pair
Taiwan well-known brand cam manipulator tool change device, stable and reliable tool change system

Standard Configuration:
· Taiwan spindle
· Rigid tapping
· Cam-type tool magazine
· Fully enclosed protective cover
· Electronic handwheel
· Lighting device
· Double spiral chip conveyor
· Automatic lubrication system
· Electrical box constant temperature device
· Spindle tool cooling system
· Toolbox
· Air gun
Special Configuration:
· Tool holder
· 30/40/60 cam-type tool magazine
· Three-axis grating ruler detection device
· Workpiece measurement system
· Tool measurement system
· Spindle internal cooling device
· 0.001° CNC rotary table
· Chain-type chip conveyor
· Tool length setter and edge finder
· Oil-water separator
· Network function
