Machine Tool Features:

The base adopts an inverted "T" layout, with high overall structural rigidity, and no overturning torque is generated during the full stroke.
The indexing table is 1°x360, positioned by a ratchet disc, with high positioning accuracy.
Heavy-duty high-precision roller guides are used, which can withstand heavy-load cutting and have good shock absorption.
A customized high-speed electric spindle is adopted, with a spindle air curtain protection device to ensure the finish of machined parts.
This compound machine adopts a vertical and horizontal compound head, which greatly improves processing efficiency and effectively reduces the floor space.

Standard Configuration:
· Mitsubishi M80A CNC system
· Cutting coolant system
· Automatic centralized lubrication system
· Heat exchanger
· Hand pulse generator
· Work lighting
· Mechanical abnormal condition indicator light
· Pause and work completion indicator lights
· BT40/24T arm-type tool magazine
· Two screws + one chain chip removal
· Full shield sheet metal
· Tools and toolbox
· Leveling bolts and foundation blocks
· Spindle oil cooler
· (1°x360) CNC turntable
· Worktable oil circuit output
Optional Configuration:
· Mitsubishi M80/Siemens 828D
· Tool bodies, tools, fixtures
· Voltage stabilizer
