Overview:
The multifunctional crystal extraction cart is a specialized handling equipment in the photovoltaic crystalline silicon manufacturing process, mainly used for the safe extraction, transfer, and docking of monocrystalline silicon rods. The equipment has a stable structure and flexible operation, effectively improving production efficiency and reducing the risk of manual handling, and is suitable for links such as crystal extraction from single crystal furnaces, crystal rod transfer, and process docking.
Working Principle:
The crystal extraction cart realizes precise clamping and movement of crystal rods through manual or electric lifting devices, sliding guide rails, crystal rod clamping mechanisms, etc. Cooperating with the height of the furnace outlet and the receiving table, it ensures a stable, safe, and damage-free crystal extraction process. Some models are equipped with functions such as automatic centering, limit protection, and emergency braking to ensure operational safety.
Features:

Flexible steering and convenient movement. Adopting a high-sensitivity万向轮 design, suitable for narrow spaces in workshops, enabling easy steering and precise positioning.
Simple operation, safe and labor-saving. Equipped with a wireless remote control handle, the operator can operate remotely from the side of the vehicle, reducing labor intensity and ensuring operational safety.
High safety design. With multiple active safety functions such as hydraulic overload alarm, obstacle sensing, and anti-piercing foot protection, ensuring the entire operation process is controllable.
Intelligent control system. Equipped with a PLC control platform, all operating statuses and parameters are visualized in real-time, supporting one-key adjustment through the human-machine interface, improving system response and data traceability capabilities.
Strong load-bearing capacity, capable of stably clamping monocrystalline silicon round rods weighing up to 1.6 tons, adapting to the load requirements of current mainstream crystal extraction processes.
Strong battery life and quick battery replacement. Standard modular quick battery replacement system supports long-term continuous operation, effectively reducing downtime caused by charging.
Note: The forward-facing vehicle body is used in environments with wider workshop aisles and larger turning radii, the lateral vehicle body is used in environments with narrow rod extraction spaces, and the lateral vehicle body is heavier than the forward-facing vehicle body.
