Output Power
620-645W
15-year Product Warranty
30-year Power Warranty
Rectangular Cell Technology
Ultra-high Efficiency
Bifacial Power Generation
Ultra-low Degradation
Stable and Reliable
Ultra-long Warranty
Applicable to:
Residential Roofs
Commercial and Industrial Roofs
Ground-mounted Power Plants
Mechanical Parameters:
Number of Half-cut Cells: 156 (78x2)
Module Dimensions: 2465x1134x30mm
Weight: 34.2kg
Front Glass: 2.0mm High-transparency Tempered Glass
Back Sheet: 2.0mm Heat-strengthened Glass
Frame: Anodized Aluminum Alloy
Junction Box: IP68 Rating / 3 Diodes
Cable: 4mm'/+300mm-300mm (Custom Cable Length Available)
Module Fire Rating: C
Safety Protection Class: Class ||
Quantity per Pallet: 36 Pieces per Pallet
Loading Quantity: 40ft High Cube: 648 Pieces, 13m Flatbed Truck: 720 Pieces, 17.5m Flatbed Truck: 936 Pieces
Temperature Parameters:
Voltage Temperature Coefficient: -0.28%/°C
Power Temperature Coefficient: -0.29%/°C
Current Temperature Coefficient: 0.04%/°C
Nominal Operating Temperature: 45±2℃℃
Maximum Rated Parameters:
Operating Temperature Range: -40°C~+85°C
Maximum System Voltage: DC 1500V
Maximum Overprotection Current: 25A/30A
Power Tolerance: 0~+5W
