Product Features
BRTIRUS1510A is a six-axis robot developed for complex applications with multiple degrees of freedom, featuring a maximum load capacity of 10kg and an arm span of 1500mm. Adopting a lightweight arm design, it has a compact and concise mechanical structure, enabling flexible operations in narrow workspaces under high-speed motion to meet the needs of flexible production. With the flexibility of six degrees of freedom, it can handle scenarios such as loading/unloading, injection molding, die casting, assembly, gluing, grinding, and inspection with ease. Simple operation - adopts Huacheng control system. Suitable for injection molding machines: 200T-600T. High protection level: IP54 dustproof and waterproof.
High precision: Repeat positioning accuracy ±0.05mm.
BRTUS1510AFZ·
Model + Non-magnetic Separator
BRTUS1510AHM·
Model + Sponge Suction Cup
BRTUS1510ALB
Model + Axial Force Position Compensator
BRTUS1510AQD.
Model + Pneumatic Floating Electric Spindle
BRTUS1510AQQ·
Model + Pneumatic Floating Pneumatic Spindle
