Device Model: WL-DCS200
Axis Parameters:
XYZ Axis Travel: 300*245*150mm
Processing Range: 200*240*100mm
Maximum Speed: 1000mm/s
XY Axis Positioning Accuracy: ±3um
XY Axis Repeat Positioning Accuracy: ±1um
Z Axis Positioning Accuracy: ±10um
Z Axis Repeat Positioning Accuracy: ±3um
Laser Parameters:
Laser Wavelength: 532nm
Laser Power: 50W/60W
Water Jet Parameters:
Nozzle Diameter: 30-70um
Water Pressure: 5-50Mpa
Usage Requirements:
Power Supply Requirement: AC380V 10KW
Air Supply Requirement: 0.6Mpa Compressed Air
and 0.15Mpa Helium Gas
Water Supply Requirement: City Water 0.4Mpa, 1-10L/H
Ambient Temperature: 22±2℃
Ambient Humidity: 30-70%RH
Other Configurations:
Sample Visual Positioning: Standard
Jet Position and Angle Detection: Standard
Auto-Focus: Optional
Automatic Power Measurement: Optional
Cut-Through Detection: Optional
