Machine Tool Features:

The bottom is of an integrated design with internal reinforcing ribs added and enlarged for high rigidity. The overall mechanical structure is made of Gb300 castings to ensure long-term non-deformation.
Ultra-wide column design increases the contact area with the crossbeam, reducing vibration during machining.
Box-type crossbeam design, combined with a double-layer rib reinforcement structure, doubles the crossbeam rigidity and enhances the durability of mechanical accuracy and the stability of machining precision.
Integrated machine head significantly improves structural rigidity, effectively preventing the impact of resonance and thermal changes, and strengthens cutting rigidity.
Optional high-horsepower spindle with a 6000r.p.m two-speed stepless variable speed gearbox, providing heavy cutting capability at low speeds and finish cutting capability at high speeds, with a wide processing range.
Integrated sliding seat with dual oil pressure configuration. The optimal position of the Z-axis screw and the center of the double symmetric counterweight oil pressure cylinder can eliminate unbalanced torque, ensuring the accuracy of micro-feeding and long-term machining precision.

Standard Configuration:
· Control System
· Separate Handwheel
· Fully Enclosed Guideway Protection
· Cooling System Device
· Centralized Automatic Lubrication System
· Electrical Control Box Heat Exchanger
· Spindle Blowing Device
· Spindle Oil Temperature Cooling Machine
· Spindle Balance Mechanism
· Screw-Type Cutting Conveyor
· Chain-Type Cutting Conveyor
· Mobile Chip Collection Bucket
· Work Light
· Warning Light
· Foundation Pads and Adjusting Bolts
· A Set of Tools and Toolbox
· Operation Manual
Special Configuration:
· Automatic Tool Changer System
· Rotary Worktable
· Auxiliary Worktable
· Automatic Tool Length Measurement
· 90-Degree Head
· Extension Head
· Universal Head
