"Juéyǐng" Six-Electrode Three-Arc Welder, Fast Speed, High Efficiency:
① Compared with traditional welders, Zhimade "Juéyǐng" six-electrode three-arc welder realizes fully automatic welding without groove for materials below 18mm, which can help manufacturers greatly improve production efficiency and product quality.
② "Juéyǐng" six-electrode power supply group, with three arcs welding simultaneously, can generate a higher temperature welding area in a short time, and the welding speed is 3-5 times that of traditional welders;
③ Equipped with adaptive thrust current adjustment function and automatic arc voltage adjustment (variable speed wire feeding) system, it has fast speed and high control precision, further improving welding efficiency;
④ Strong current, stable arc, fast arc starting, continuous welding without arc breaking, saving time and effort;
⑤ Meet the requirements of wider weld gaps, the connection after welding is tighter and firmer, and the welding quality is guaranteed.
"Wūzhuī" Six-Electrode Six-Arc Welder, Thick Plate One-Time Forming:
① "Wūzhuī" six-electrode six-arc welder, matched with carbon steel deep penetration K-TIG welding technology, six electrodes and six arcs generate large and concentrated heat, with strong penetration, and can realize groove-free welding for webs below 25mm when welding plates;
② The front torch adopts DC flat characteristic and the rear torch adopts DC pulse mode, which not only ensures the penetration depth but also takes into account the cover surface forming, reduces heat input, avoids the damage of thermal effect to the plate, and effectively solves the automation technical problem of one-time forming of thick plate welding:
③ Smooth arc starting, stable arc, effectively realizing stable welding surface forming, beautiful weld, small deformation, and high component qualification rate;
④ Solid core welding wire, automatic wire feeding, giving full play to the advantages of large current and high deposition rate of submerged arc welding, improving welding efficiency and weld quality;
⑤ According to the hardness of the steel, high-performance flux is selected, which has stable arc, good weld formation, fast slag removal, and less welding fume generated during the welding process.
Intelligent IoT, Simple Operation:
① 15-inch touch screen, displaying welding data in real time, enabling intuitive understanding of equipment working status and more convenient operation;
② Independent adjustment of welding current and voltage, built-in multiple process parameter templates, which can be edited and modified by users;
③ Can independently control the working status of front and rear torches to be compatible with conventional welders:
④) Can choose Zhimade intelligent IoT system to realize automatic calculation of welding wire and flux consumption, accurate statistics of welding output, and remote control to escort stable production;
⑤ The welding power supply has high efficiency, large power, low no-load loss, and more energy-saving, equipped with overvoltage, undervoltage, phase loss and overheating protection functions;
⑥ Compact structure, small size, light weight, more flexible to use.
Wide Application, Reliable Quality:
① Ten years of experience in R&D and production of steel structure equipment, source factory, perfect quality system, and guaranteed products;
② Parts are all from well-known domestic brand suppliers, with good whole machine matching and stable performance;
③ Widely used, has been applied in steel structure processing, aerospace, locomotives, ships, petrochemical, substations, automobiles and other fields;
④ One-time purchase, lifetime warranty, professional after-sales personnel guide installation and use, and after-sales service is guaranteed.
