Applicable Materials:
· Cement mortar
· Finished mortar
· Self-mixed mortar
· Anti-crack mortar
· Lightweight gypsum
· Heavy gypsum
· Polymer mortar
· High ductility mortar
Applicable Scenarios:
· Public construction projects
· Housing construction projects
· Municipal projects
· Office buildings
· Warehouses
· Industrial plants, etc.
Product Advantages:
Patented technology microcomputer automatic leveling system, no need for screeding, with an error within 2mm. Adopting Siemens PLC + imported servo motor + industrial control LCD screen,
automatic control with adjustable speed, not limited by construction site voltage and power supply, no need for wiring and electricity connection, 48V large battery,续航10小时以上. Patented independent suspension chassis, easily leveling uneven construction ground. Patented plastering scraper device, integrating troweling, patching, and scraping into one. The main machine, track, and scraper are connected by卡扣 (patented technology), no need for screw fixation, high application efficiency. Patented lifting safety protection device to prevent machine damage caused by accidents during machine lifting.
High Efficiency:
Single person single machine plastering 4㎡/min, can replace 5~8 workers.
High Quality:
Vertical and flatness error within 2mm, adhesion is 2.5 times that of manual work, ensuring construction quality.
High Profit:
Save more than 60% of labor costs.
The cost can be recovered with 10,000㎡ construction area.
Product Parameters:
Plastering Height: 440cm
Plastering Width: 80cm (100cm, 120cm optional)
Working Efficiency: 4㎡/min
Working Voltage: 48V (battery)
Motor Type: Servo motor
Positioning Method: Microcomputer vertical instrument + positioning points (visual sensing system optional)
Product Weight: About 180kg
Overall Dimensions: 110*70*193cm
