The power frequency single-stage screw air compressor adopts the industry-leading screw host, with high efficiency and low speed. The rotor uses the third-generation tooth profile and leading excellent profile design; it has the characteristics of mute, energy saving, stability, high reliability and long service life. It uses a special low-speed screw air compressor professional motor with high stability, which has a 3-5% efficiency improvement compared with similar products.
The direct connection structure has no loss, 100% transmission efficiency, low maintenance cost, convenient disassembly, and greatly saves downtime. The coaxial integrated structure has no loss, reduces vulnerable parts, and the transmission rate is 100%.
A low-speed fan is used, with a long service life. The cooler and fan can be disassembled independently, with 20% cooling margin. It can adapt to an ambient temperature of 50 degrees Celsius. The power frequency compressor is equipped with an intelligent control system to ensure fully automatic intelligent operation. It detects on-site data such as exhaust pressure and temperature, and controls the exhaust pressure between the preset upper and lower pressure limits through the intake valve, thereby outputting a stable pressure.
Application of microcomputer control system:
Environmentally friendly, durable, small vibration, low noise; high efficiency, heavy load, mute
