Overall Dimensions:
W1960*D670*H1660mm
Hopper Inlet Dimensions:
640*500mm
Hopper Inlet Height:
930mm
Hopper Capacity: 70L
Oil Receiver Capacity: 47L
Chip Compression Method: Oil Cylinder
Compressed Dimensions:
30030030~80mm
Maximum Pressing Force: 100 tons
Applicable Materials: Long filaments/coiled materials of different materials such as aluminum/stainless steel/iron/copper/magnesium alloy
Cycle Time: Approximately 36 seconds (excluding the time to feed into the compression section)
Weight: 1400kg
Power Supply: 3-phase 380V
Power: 7.5KW
