●The iron core of the 35kV class oil-immersed power transformer is made of high-quality oriented silicon steel sheets with multi-stage stepped lamination, and the surface is coated with curing paint. It features low loss, low noise, etc. The coil adopts a new type of oil passage structure that is conducive to heat dissipation, and the insulation process is optimized with reasonable structure, which effectively improves the heat dissipation capacity and short-circuit impact resistance of the coil, ensuring reliable operation. The tank wall of the oil tank adopts a one-time forming bent corrugated structure, which increases the mechanical strength of the oil tank and has an elegant appearance.
●Suitable for power plants, substations (distribution stations), industry and other fields.
●Implements national standards such as GBI094 and GB6451.
