Online Thickness Measurement for Vacuum Coating
Online Detection of Optical Density (OD Value)
Online Detection of Transmittance
LS152 (Model): Product Features: Vacuum coating online monitoring system, light source wavelength and measurement points can be customized, supporting up to 45 points, RS485/MODBUS support, PLC programming support, optional human-machine interface
LS153 (Model): Product Features: Vacuum coating online monitoring system, light source wavelength and measurement points can be customized, supporting up to 45 points, RS485/MODBUS support, PLC programming support, optional human-machine interface
This is a fully customized online thickness measurement equipment for vacuum coating. It utilizes the principle that the transmittance (optical density) of a material is proportional to its thickness. By monitoring the optical transmittance (optical density) of the material, it achieves the purpose of monitoring the uniformity of the material and the thickness of the coating. The equipment adopts an RS485 communication interface and supports the standard MODBUS communication protocol, which can be connected to a human-machine interface, PLC or computer to realize closed-loop control. It is commonly used for online quality monitoring in roll-to-roll vacuum coating machines, coating machines, and glass production lines. The equipment consists of a measurement and control host and a human-machine interface control box.
Core Advantages:

Ultra-small digital probe, extremely simple to use and install, only 6 wires need to be connected
High measurement accuracy, comparable to German NAGY online thickness measurement equipment
Optical non-contact measurement, no direct contact with the test material, no damage to the material
Modular design, single points can be disassembled, convenient for future maintenance
Dust-proof design, dust does not affect the inside of the probe, only the glass at the front end of the probe needs to be cleaned
RS485 interface + MODBUS communication protocol, can communicate with coating machine to realize closed-loop control
Over-limit alarm function, intelligent control of production quality, reduce dependence on personnel, improve production efficiency and quality
